Profiled wire surfaces

Dimensions:

Square wires and other shapes acc. to your specifications and request

Tin [Sn]

Electrolytically tin-plated round (Electrolytically tin-plated flat) (Electrolytically tin-plated profiled) wires for all areas of electrical engineering including highly automated soldering processes. Also suitable as protection when processing aggressive plastics. Optionally with a nickel or copper barrier layer. Packaging: Spools or coils

Profiled and square wires on request, fused tin surfaces also possible.

Dimensional range (Sn):
Profiled and square wires on request

Feel free to contact us for a quote. Please click here.

Silver [Ag]

Silver-plated copper wires for the cable industry with up to 100 g/kg of plating. Silver-plated coaxial conductor centres for HF technology. Switch and connector wires for electronic components as well as profiled wires for busbars. Silver-plated, drawn bronze or steel wires for electrical contacts.

Dimensional range (Ag):
Profiled and square wires on request

Feel free to contact us for a quote. Please click here.

Nickel [Ni]

Non-porous, nickel-plated copper wires in line with ASTM standards, with up to 27% nickel by weight . Nickel-plated wires for protection against thermal stresses up to approx. 400°C or against corrosive evaporation of plastics in electrical engineering and electric current carriers. Nickel-plated iron wires with up to 4% nickel by weight . Decorative, flexible, bright nickel layers on iron or steel wires for bulk wire products.

Dimensional range (Ni):
Profiled and square wires on request

Feel free to contact us for a quote. Please click here.

Gold [Au]

Tarnish-proof contact, spring and connector wires made from copper, pure nickel or alloys, stainless steels with a fine gold plating up to 1 µm thick. Can also be manufactured with a nickel barrier or with a copper or silver interface layer for increased electrical conductivity.

Dimensional range (Au):
Profiled and square wires on request

The gold layers can be supplied as hard gold according to MIL G45204C Type 1 Grade C.

Feel free to contact us for a quote. Please click here.
